X3348TR

Switching Features:
- Link Aggregation - 24 groups w/ 8 members per group
- LACP Support
- MLAG Support
- Link Layer Discovery Protocol (802.1AB)
- Jumbo Frame Support
- Port Mirroring - N to 1. Tx & Rx Configurable
Routing Features:
- Static Routing, RIP v1/v2, RIPng, OSPF v1/v2/v3 & BGP
- IPv4 and IPv6 Routing
- VRRP (Virtual Router Redundancy Protocol)
- DVMRP (Distance Vector Multicast Routing Protocol
Port Attributes:
- 48 10GBase-T Ten-Gigabit Ethernet ports - RJ45 Connectors
* Energy Efficient Ethernet (IEEE 802.3az)
- 4 Forty-Gigabit Ethernet ports -QSFP Connectors
- 2 One-Gigabit Ethernet ports -RJ45 Connectors
- Out-of-band RS-232 Management port
Performance:
- Switching capacity: 1284 Gbps
Availability:
- Spanning Tree (802.1D)
- Rapid Spanning Tree (802.1w)
- Multiple Spanning Trees (802.1s)
- Virtual Redundant Routing Protocol (VRRP)
VLAN:
- 802.1Q tagging, port and protocol based
- 4K VLANs
- Dynamic VLAN Support (GVRP)
Quality of Service and DiffServ:
- 8 priority queues per port
- Adjusted WRR and Strict Priority Scheduling
- Layer 2 / 3 / 4 Prioritization
- Marking
- Metering / Rate limiting
Multicast:
- IGMP Snooping v1/ v2/ v3
- IGMP v1/ v2/ v3
- PIM SM, PIM DM
- PIM SMv6
Security:
- 802.1x Port Based Authentication
- Switch access password protection
- Layer 2 / 3 / 4 Access control Lists
- RADIUS and TACACS+ Authentication
- SSH / SSL Encryption
Management:
- Web-based management interface
- HTTP, HTTPS
- Telnet (4 sessions)
- Industry standard CLI with telnet, SSH or local management port
- Scripting capability
- Command completion
- Context sensitive "Help"
- Multiple levels of user privileges (CLI and Web UI)
- SNMP v1/v2/v3
- Four RMON Groups - (1, 2, 3 and 9)
- Logging - syslog
- Dual firmware images
- Configuration file - upload / download
Dimensions:
- 17.3" W x 18.6" D x 1.7" H
(440mm W x 473mm D x 43mm H)
Weight:
- 20.3 lbs / 9.22 kg
Power:
- Dual 400W Hot-swap Redundant Power Supplies
- Power Consumption of 375W
Operating Temperature:
- 0° to 45°
